Key Features

· Mini-LED

·144Hz Game Mode Pro

· Quantum Dot Colour

· Dolby Vision IQ

· Built-in Subwoofer

· AMD FreeSync Premium

Image display
Panel manufacturer
Hisense
Panel model
LCM:HD850H6U51-T0L1K1, Open Cell : T850QVN03.7
Active display area, horizontal dimension
2203
Active display area, vertical dimension
1239
Screen size (rounded to nearest integer)
254
Screen size (rounded to nearest integer)
100
Display technology
LCD/ LED lit
Backlight source
Direct LED
Resolution (Horiz x Vert)
3840X2160
Screen curvature radius
-
Colour depth
8bit+FRC
Image refresh frequency
144
Smooth motion rate
240
3D image
-
Typical brightness of white
500
Native contrast ratio
5000 : 1
Viewing Angle (Horiz / Vert)
178/  178
Quantum dot
Yes
Wide colour gamut
Yes
KSF phosphor
No
UHD Premium
No
Response Time
6,5

Connectivity
RF- Radio frequency input
1
AV input
1
AV output
0
USB interface type 3.0 (Qty / List….)
1/ USB1
USB interface type 2.0 (Qty / List ….)
1/ USB2
Optical digital audio output (SPDIF)
1
Earphone jack
1

HDMI ports
HDMI inputs
4
HDMI type 8K@60Hz
No
HDMI type 4K@60Hz with HDCP version 2.2
Yes
HDMI 2.1  compliant input
Yes / HDMI 3 & 4
Enhanced Audio Return Channel ( eARC)
Yes / HDMI 3
CEC- Consumer Electronics Control via HDMI
Yes

Smart TV
Ethernet port (RJ45 connector)
1
Wi-Fi  protocols IEEE 802.11 {b, g, n, ac, ad, ..}
a, b, g, n, ac
Wi-Fi bands
2.4/5.0
DLNA compliance
Yes
Bluetooth / BT version
Yes / 5.0
Anyview (Screen mirroring)
Yes
BVOD services (Iview,  SBS on Demand, 9Now, 7Plus, Tenplay)
Iview,  SBS on Demand, 9Now
Installed Applications {List ……}
Netflix/Youtube/Prime Video……
Freeview Plus - HbbTV 2.0
Yes
Web browser [Chrome | Opera | Other]
Odin

Digital TV reception
Digital broadcating (DVB-T / DVB-T2)
Yes / Yes
Video decoder (MPEG2 / MPEG 4)
Yes / Yes
LCN- Logical channel number and DTV Service name support
Yes
Teletext  / Teletext signal interruption (TAB compliant) / 16 : 9 TLTX
Yes / Yes / 4:3
Subtitles
Yes
EPG- Electronic programming guide, 7 days for all services
Yes
Audio description (vision impairment aid)
Yes
Parental rating lock
Yes
Analog Tuner
Yes

Image processing
Backlight control
Yes
Light sensing
YES
Dynamic backlight control
YES
Frame rate control
No
Variable Refresh Rate (VRR)
Yes
FreeSync
Yes
Auto Low Latency Mode for VRR
Yes
Local dimming/ controllable zones
Yes/ 1296
Zoom function settings
Auto/ 16:9/ 4:3/21:9/Movie Zoom/ Dot to Dot
HDR - High Dynamic Range for luminance (DMP / Netflix / HDMI)
Yes / Yes/ Yes
HDR system (HDR10 / HDR10+ / Dolby Vision)
Yes /Yes/Yes
HLG (Hybrid Log-Gamma) for HDR
YES
HEVC (H.265) decoder
Yes
Motion enhancement and compensation (MEMC)
Yes
Picture mode
Standard,Cinema Day,Cinema Night,Dynamic,Sports

Sound
Audio power output per channel
2*15W+20W+2*5W
Number of speakers (Tweeter / Midrange / Woofer)
2 /2 /1
Automatic volume level (AVL)
Yes
Audio equalizer
Yes
Dolby Digital
Yes
Audio enhancement -Type {SRS, BBE, SAP, DBX-TV….}
Dolby ATMOS
Lip-sync  adjustment
Yes
Sound mode
Stand,Theatre,Music,Speech,Late Night,Sports.

Features
On/off timer
Yes
Power off if no signal
Yes
Sleep timer
Yes
Program lock
Yes
OSD transparency control
Yes
User interface
VIDAA U7
Software version OSD indication
Yes
Legal requirements: Disclaimer / Acceptance of Terms
Yes / Yes
Favourite channels list
Yes
Electronic point of sales (E-POS)
Yes
OTA- Over the air software updates
Yes
Voice command
Yes
Screen mirroring {Miracast, Anyview Cast, ...}
Anyview Cast
Smartphone remote control application {Rremote Now, ...}
vidaa app
Replaceable demo video for Store mode
Yes
Remote control via serial port
No

USB media player
Personal Video Recorder
Yes
Time Shift
Yes
DTV Recording (EPG scheduling / start from Standby )
Yes / Yes
DivX decoder
No
MPEG4 (H.264) / H.265 decoder
Yes / Yes
DMP- Digital media player content (Music / Video / Photos / Text)
Yes / Yes / Yes / No
DMP Auto-play
No
DMP for UHD content via USB
Yes
DMP File allocation table (FAT / FAT32 / exFAT / NTFS)
Yes / Yes  / No / Yes
PVR  File allocation table (FAT / FAT32 / exFAT / NTFS)
Yes / Yes / No / Yes

Hotel lock
Protected Hotel lock submenu (Password / fixed code)
No / Yes
Clone function for programs, sound and image settings.
Yes
Sub-menu lock, including tuning lock
Yes
Keyboard lock
Yes
Maximum volume lock
Yes
Power on volume
Yes
Power on, apply default sound/image settings
No
Power on source selection
Yes
Power on RF channel selection
Yes
Power on mode (On / Standby / Last)
Yes / Yes / Yes
Inputs access (Enable / Disable)
Yes

Hardware
Processor / Cores
MT9618BAATAB
Dual Tuner
No
Colour (Front bezel, rear, stand)
Tarnish / Black /  Tarnish
Speakers mounted in enclosure
Yes
Mains  power switch
No
Swivel base
No
Compact packaging

Yes
Supply  range [Voltage / Frequency ]
AC100~240V,50Hz/60Hz
Standby consumption
< 0.5W
Maximum time delay Power On to sound an image
30


Installation
Stand area (Width / Depth)
1682×455
Wall mount dimensions (Horiz x  Vert)
600×400
Wall mount, screw thread
M8/10
VESA compliance
Yes
Detachable power cord
Yes
Power cord length
200

Accessories
Remote controller (Technology / Part number )
IR /ERF2R36H

Battery (size / quantity)
AAA / 2

User manual (Available online) / Quick setup guide (Print)
1 / 1

Warranty [In User manual | In separate sheet]
In separate sheet

Skype camera (Qty / Part number)
-

3D glasses type  [Passive | Shutter] / Link [RF | IR | BT]
-

3D glasses (Qty / Part number)
-


Dimensions
Dimensions with stand (W x H x D)
2235×1318×500
Dimensions without stand (W x H x D)
2235×1286×90
Carton box dimensions (W x H x D)
2402×297×1514
Net weight (with stand / without stand)
73.5 Kg/71.3 Kg
Gross weight
100 Kg

Container load (20ft / 40ft / 40ft HC)
35（40ft HC)

Licensing and certification
EMC- Electromagnetic Compatibility
Yes
CB- Electrical safety
Yes
HDMI
Yes (Hisense internal test)
Dolby Digital
Yes
MEPS- Test report
Yes
ROHS
No
Electrical safety  conformity for Australia
Yes
