TYPE
Product Family:Hob
Dimensions:90 cm
Type:Mixed
Built-in type:Traditional
Power supply:Mixed
EAN code:8017709313579

AESTHETICS
Colour:Black
Finishing:Glass
Aesthetic:Dolce Stil Novo
Material:Glass
Glass type:ceramic Eclipse
Controls colour:Steel effect
Type of control setting:Multi Slider
Control knob position:Front
No. of controls:1
Slider:Yes
Glass edge:Straight edge
Glass on Steel:Yes
Pan stands:Cast iron
Burners:Smeg Contemporary
Burners Material:Brass
Serigraphy colour:Grey

PROGRAMS / FUNCTIONS
Total no. of cook zones:5
No. of gas cook zones:1
No. of induction cook zones:4
Time-setting options:Spegnimento automatico
No. of cooking zones with booster:4
No. of Flexible zones:2
Main on/off switch:Yes
Power levels:9
Auto-vent 2.0:Sì

OPTIONS
Worktop Cut-Out:482-486x844-848 mm
Double Booster:Yes
Multizone Option:Yes
Auto Multizone:Yes
Flexible Zone Type:MultiZone
End cooking timer:4
Pause option:Yes
Minute minder:1
End of cooking alarm:Yes
Residual time indicator:Yes
Limited Power Consumption Mode:Si Advance
Limited Power Consumption Mode in W:2400 a 7400 - step 100 W
Showroom Demo Option:Yes
Grill function:Yes
Control Lock / Child Safety:Yes
Keep warm automatic function:Yes
Bridge option:Yes
Quick start:Yes
Rapid level selection:Yes

COOKING ZONES
1st zone position:Centre-left
2nd zone position:Rear-centre
3rd zone position:Front-centre
4th zone position:Rear-right
5th zone position:Front-right
1st zone type:Gas - UR
2nd zone type:Induction - Multizone
3rd zone type:Induction - Multizone
4th zone tipe:Induction - Multizone
5th zone type:Induction - Multizone
2nd zone dimensions:24.0x18.0 cm
3rd zone dimensions:24.0x18.0 cm
4th zone dimensions:24.0x18.0 cm
5th zone dimensions:24.0x18.0 cm
Central Multizone dimension:38.5x23.0 cm
Right Multizone dimension:38.5x23.0 cm
1st zone power:6.00 kW
2nd zone power:2.10 kW
3rd zone power:2.10 kW
4th zone power:2.10 kW
5th zone power:2.10 kW
Power double booster 1° zone:3 kW
Power double booster 2° zone:3 kW
Power double booster 3° zone:3 kW
1st zone booster power:2.5 kW
Power double booster 4° zone:3 kW
Power double booster 5° zone:3 kW
2nd zone booster power:2.50 kW
3rd zone booster power:2.50 kW
4th zone booster power:2.50 kW
5th zone booster power:2.50 kW
Booster power left Multizone:3.7 kW
Booster power central Multizone:3.7 kW
Booster power right Multizone:3.7 kW

TECHNICAL FEATURES
Gas Type:G20 Natural gas
Automatic setting according to pan dimension:Yes
Permanent Automatic Pot Detection with indication of the relative control:Yes
pan detection:Yes
Gas safety valves:Yes
Automatic Ignition:Yes
Automatic switch off when overheat:Yes
Automatic switch off when overflow:Yes
Residual heat indicator:Yes
Protection against accidental start up:Yes

PERFORMANCE / ENERGY LABEL
2nd zone energy consumption:195 Wh/Kg
Energy consumption zone 3:195 Wh/Kg
Energy consumption zone 4:195 Wh/Kg
Energy consumption zone 5:195 Wh/Kg

ELECTRICAL CONNECTION
Gas connection rating (W):6000 W
Electrical connection rating (W):7400 W
Voltage (V):220-240 V
Voltage 2 (V):380-415 V
Frequency (Hz):50/60 Hz
Type of electric cable installed:Yes, Single and Double phase
Power supply cable length:120 cm

LOGISTIC INFORMATION
Dimensions of the product (mm):45x900x510
Depth:510 mm
Width:900 mm
Product Height:45 mm
Net weight (kg):17.600 kg
Gross weight (kg):20.300 kg
