JBL SB580 3.1 Soundbar 440W - CON000126
JBL SB580 3.1 Soundbar 440W - CON000126
JBL SB580 3.1 Soundbar 440W - CON000126
Description
Thunderous Bass. Immersive 3D sound
Step into a world of immersive home audio with the JBL Cinema SB580 soundbar. An explosive 440 watts of powerful Virtual Dolby Atmos® sound in a compact design plus thunderous extra-deep bass from a 6.5” wireless subwoofer combine to surround you in a whole new level of sound. A dedicated center channel means TV and film dialogue is always crystal clear. High-resolution HDMI eARC, HDMI, or optical connections give you plenty of easy set-up options. And when the TV is off, seamless Bluetooth connectivity means you can use it to play all your favorite streaming music and podcasts from any device.
General Specifications
Model
CINEMA SB580
Sound system
3.1 channel
Power supply
100 - 240V AC, ~ 50/60Hz
Total speaker power output (Max @THD 1%)
440W
Soundbar output power (Max @THD 1%)
240W
Subwoofer output power (Max. @THD 1%)
200W
Soundbar transducer
3x (45 x 100) mm racetrack drivers + 3x 13mm tweeters
Subwoofer transducer
6.5” (165 mm), wireless subwoofer
Standby power
< 0.5 W
Operating temperature
0°C - 45 °C
Audio Specifications
Frequency response
40Hz-20kHz (-10dB)
Audio inputs
1 Optical, Bluetooth and USB (USB playback is available in US version. For other versions, USB is for Service only.)
Dimensions
Soundbar dimensions (W x H x D)
950 x 64 x 80 mm / 37.4’’ x 2.5’’ x 3.1’’
Subwoofer dimensions (W x H x D)
200 x 404 x 250 mm / 7.9" x 15.9" x 9.9"
Soundbar weight
2.6kg / 5.7 lbs
Subwoofer weight
5.7 kg / 12.6 lbs
Packaging dimensions (W x H x D)
1025 x 235 x 397 mm / 40.4" x 9.3" x 15.6"
Packaging Weight
10.4 kg / 22.9lbs
Control and Connection Specifications
USB port
Type A
USB rating
5V DC, 0.5A
Supporting file formats
mp3
MP3 codec
MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate
16 - 48 kHz
Bluetooth version
5.3
Bluetooth profile
A2DP 1.3, AVRCP 1.6
Bluetooth transmitter frequency range
2400 MHz – 2483.5 MHz
Bluetooth Max. transmitting power
<10 dBm (EIRP)
Bluetooth modulation
GFSK, π/4 DQPSK, 8DPSK
2.4G wireless transmitter frequency range
2402-2481 MHz
2.4G wireless transmitter power
<10dBm (EIRP)
2.4G wireless modulation
GFSK
Video Specifications
HDMI video input
1
HDMI video output (with Enhanced Audio Return Channel, eARC)
1
HDMI HDCP version
2.3
What's in The Box?
•Soundbar
•Wireless subwoofer
•Remote control with batteries
•Power cords (up to 8pcs depending on region SKUs)
•HDMI cable
•Wall-mount bracket kit with screws
•Quick start guide
•Warranty card
•Safety sheet
SKU | 84950 |
---|---|
Color | Black |
Brand | JBL |
Blue Tag | No |
MPN | CON000126 |
EAN | 1200130009259 |
